High Pressure Producing Line Hose Clamp Assembly Machine
Model Specifications
- Machine Dimensions: 7,050 × 1,700 × 1,900 mm
- Production Capacity: Up to 400 hoses per hour
Product Overview
The High Pressure Hose Assembly Machine is a fully automatic assembly system designed for manufacturing high-pressure cleaning hose assemblies.
The hose is manually loaded by the operator, while protective sleeves, nuts, ferrules, fittings, O-rings, and other components are automatically supplied through dedicated feeding systems. The machine completes component assembly and servo-controlled crimping in one continuous production process, delivering stable production quality and high manufacturing efficiency.
Key Features
- Manual hose loading
- Automatic feeding of protective sleeves
- Automatic nut feeding
- Automatic ferrule feeding
- Automatic fitting feeding
- Automatic O-ring feeding
- Automatic component assembly
- Servo-controlled crimping
- Integrated automatic production process
Advantages
High Production Efficiency
Designed for continuous production with an output of up to 400 hose assemblies per hour.
Stable Component Feeding
Protective sleeves, nuts, ferrules, fittings, O-rings, and other components are automatically supplied to ensure smooth and reliable production.
Precision Servo Crimping
The servo-driven crimping system provides stable operation and consistent crimping quality.
Reduced Manual Operation
Only the hose requires manual loading, while the remaining assembly operations are completed automatically, improving productivity and reducing labor intensity.
Reliable Assembly Quality
The integrated assembly process ensures consistent product quality throughout production.
Typical Production Process
- Manual Hose Loading
- Protective Sleeve Feeding
- Nut Feeding
- Ferrule Feeding
- Fitting Feeding
- O-Ring Feeding
- Component Assembly
- Servo Crimping
- Finished Product Discharge
Applications
Suitable for manufacturing:
- High Pressure Cleaning Hoses
- Pressure Washer Hoses
- Water Jet Hoses
- Industrial Cleaning Hoses
- Hydraulic Cleaning Hoses
- Flexible High Pressure Hose Assemblies
- Customized High Pressure Hose Products
Customization Options
Hotlink provides customized solutions according to your production requirements, including:
- Hose specifications
- Fitting types
- Ferrule configurations
- Sleeve designs
- Production capacity
- Machine layout
- Touchscreen language
Why Choose Hotlink?
Hotlink specializes in designing and manufacturing customized hose assembly equipment for manufacturers worldwide. Our solutions are developed to match your products, production processes, and capacity requirements, helping improve manufacturing efficiency, reduce labor costs, and ensure reliable assembly quality.
Whether you require a standalone assembly machine or a complete automated production line, Hotlink delivers automation solutions engineered for long-term performance.
Hotlink — Engineered Around Your Products. Built for Your Success.
